Standard Jacketed Fittings
CSI offers Tri-Clamp jacketed elbows, tees, reducers, and spools in a variety of sizes up to 4 inches. Every option features 316L stainless steel for the product contact surface with a 304 jacket. Three different media port configurations are available on elbows and tees. These fittings are designed for media temperatures ranging from 34°-205°F and product temperatures from 34°-300°F.
Not seeing exactly what you're looking for? Contact us for custom jacketed projects and configurations.
Models
- Elbows
- Tees
- Reducers
- Spools
Central States Industrial (CSI) offers a full range of hygienic processing equipment and services for the food, dairy, beverage, pharmaceutical, and personal care industries. CSI maintains an extensive inventory of fittings, tubing, pumps, valves, and instrumentation.
90° Jacketed ElbowsJKT-90-Size-TN6-Port Position
Diagram shows port position A
| 316L Material Part # (Port Position A) | 316L Material Part # (Port Position B) | 316L Material Part # (Port Position C) | Product Line Size (in) | Jacket Size (in) | A (in) |
|---|---|---|---|---|---|
JKT-90-0.5-TN6-A | JKT-90-0.5-TN6-B | JKT-90-0.5-TN6-C | ½ | 1½ | 3.50 |
JKT-90-0.75-TN6-A | JKT-90-0.75-TN6-B | JKT-90-0.75-TN6-C | ¾ | 1½ | 3.50 |
| JKT-90-1-TN6-A | JKT-90-1-TN6-B | JKT-90-1-TN6-C | 1 | 2 | 3.50 |
| JKT-90-1.5-TN6-A | JKT-90-1.5-TN6-B | JKT-90-1.5-TN6-C | 1½ | 2½ | 4.25 |
| JKT-90-2-TN6-A | JKT-90-2-TN6-B | JKT-90-2-TN6-C | 2 | 3 | 5.25 |
| JKT-90-2.5-TN6-A | JKT-90-2.5-TN6-B | JKT-90-2.5-TN6-C | 2½ | 4 | 6.00 |
| JKT-90-3-TN6-A | JKT-90-3-TN6-B | JKT-90-3-TN6-C | 3 | 4 | 6.75 |
| JKT-90-4-TN6-A | JKT-90-4-TN6-B | JKT-90-4-TN6-C | 4 | 6 | 8.63 |
45° Jacketed ElbowsJKT-45-Size-TN6-Port Position
Diagram shows port position A
| 316L Material Part # (Port Position A) | 316L Material Part # (Port Position B) | 316L Material Part # (Port Position C) | Product Line Size (in) | Jacket Size (in) | A (in) |
|---|---|---|---|---|---|
JKT-45-0.5-TN6-A | JKT-45-0.5-TN6-B | JKT-45-0.5-TN6-C | ½ | 1½ | 2.75 |
JKT-45-0.75-TN6-A | JKT-45-0.75-TN6-B | JKT-45-0.75-TN6-C | ¾ | 1½ | 2.75 |
| JKT-45-1-TN6-A | JKT-45-1-TN6-B | JKT-45-1-TN6-C | 1 | 2 | 2.75 |
| JKT-45-1.5-TN6-A | JKT-45-1.5-TN6-B | JKT-45-1.5-TN6-C | 1½ | 2½ | 3.00 |
| JKT-45-2-TN6-A | JKT-45-2-TN6-B | JKT-45-2-TN6-C | 2 | 3 | 3.50 |
| JKT-45-2.5-TN6-A | JKT-45-2.5-TN6-B | JKT-45-2.5-TN6-C | 2½ | 4 | 3.88 |
| JKT-45-3-TN6-A | JKT-45-3-TN6-B | JKT-45-3-TN6-C | 3 | 4 | 4.13 |
| JKT-45-4-TN6-A | JKT-45-4-TN6-B | JKT-45-4-TN6-C | 4 | 6 | 5.13 |
Standard Jacketed TeesJKT-TS-Size-TN6-Port Position
Diagram shows port position B
| 316L Material Part # (Port Position A) | 316L Material Part # (Port Position B) | 316L Material Part # (Port Position C) | Product Line Size (in) | Jacket Size (in) | A (in) |
|---|---|---|---|---|---|
| JKT-TS-1.5-TN6-A | JKT-TS-1.5-TN6-B | JKT-TS-1.5-TN6-C | 1½ | 2½ | 2.75 |
| JKT-TS-2-TN6-A | JKT-TS-2-TN6-B | JKT-TS-2-TN6-C | 2 | 3 | 3.50 |
| JKT-TS-2.5-TN6-A | JKT-TS-2.5-TN6-B | JKT-TS-2.5-TN6-C | 2½ | 4 | 3.50 |
| JKT-TS-3-TN6-A | JKT-TS-3-TN6-B | JKT-TS-3-TN6-C | 3 | 4 | 3.75 |
| JKT-TS-4-TN6-A | JKT-TS-4-TN6-B | JKT-TS-4-TN6-C | 4 | 6 | 4.50 |
Reducing Jacketed TeeJKT-TR-Size-TN6-Port Position
Diagram shows port position B
| 316L Material Part # (Port Position A) | 316L Material Part # (Port Position B) | 316L Material Part # (Port Position C) | Product Line Size (in) | Jacket Size (in) | A (in) | B (in) |
|---|---|---|---|---|---|---|
JKT-TR-1.5X0.5-TN6-A | JKT-TR-1.5X0.5-TN6-B | JKT-TR-1.5X0.5-TN6-C | 1½ x ½ | 2½ | 2.88 | 2.88 |
JKT-TR-1.5X0.75-TN6-A | JKT-TR-1.5X0.75-TN6-B | JKT-TR-1.5X0.75-TN6-C | 1½ x ¾ | 2½ | 2.88 | 2.88 |
JKT-TR-1.5X1-TN6-A | JKT-TR-1.5X1-TN6-B | JKT-TR-1.5X1-TN6-C | 1½ x 1 | 2½ | 2.75 | 2.63 |
JKT-TR-2X0.5-TN6-A | JKT-TR-2X0.5-TN6-B | JKT-TR-2X0.5-TN6-C | 2 x ½ | 3 | 3.38 | 3.13 |
JKT-TR-2X0.75-TN6-A | JKT-TR-2X0.75-TN6-B | JKT-TR-2X0.75-TN6-C | 2 x ¾ | 3 | 3.5 | 3.13 |
JKT-TR-2X1-TN6-A | JKT-TR-2X1-TN6-B | JKT-TR-2X1-TN6-C | 2 x 1 | 3 | 3.50 | 2.88 |
JKT-TR-2X1.5-TN6-A | JKT-TR-2X1.5-TN6-B | JKT-TR-2X1.5-TN6-C | 2 x 1½ | 3 | 3.50 | 3.00 |
JKT-TR-2.5X0.5-TN6-A | JKT-TR-2.5X0.5-TN6-B | JKT-TR-2.5X0.5-TN6-C | 2½ x ½ | 4 | 3.63 | 3.38 |
JKT-TR-2.5X0.75-TN6-A | JKT-TR-2.5X0.75-TN6-B | JKT-TR-2.5X0.75-TN6-C | 2½ x ¾ | 4 | 3.63 | 3.38 |
JKT-TR-2.5X1-TN6-A | JKT-TR-2.5X1-TN6-B | JKT-TR-2.5X1-TN6-C | 2½ x 1 | 4 | 3.50 | 3.13 |
JKT-TR-2.5X1.5-TN6-A | JKT-TR-2.5X1.5-TN6-B | JKT-TR-2.5X1.5-TN6-C | 2½ x 1½ | 4 | 3.50 | 3.25 |
JKT-TR-2.5X2-TN6-A | JKT-TR-2.5X2-TN6-B | JKT-TR-2.5X2-TN6-C | 2½ x 2 | 4 | 3.50 | 3.75 |
JKT-TR-3X0.5-TN6-A | JKT-TR-3X0.5-TN6-B | JKT-TR-3X0.5-TN6-C | 3 x ½ | 4 | 3.88 | 3.63 |
JKT-TR-3X0.75-TN6-A | JKT-TR-3X0.75-TN6-B | JKT-TR-3X0.75-TN6-C | 3 x ¾ | 4 | 3.88 | 3.63 |
JKT-TR-3X1-TN6-A | JKT-TR-3X1-TN6-B | JKT-TR-3X1-TN6-C | 3 x 1 | 4 | 3.75 | 3.38 |
JKT-TR-3X1.5-TN6-A | JKT-TR-3X1.5-TN6-B | JKT-TR-3X1.5-TN6-C | 3 x 1½ | 4 | 3.75 | 3.50 |
JKT-TR-3X2-TN6-A | JKT-TR-3X2-TN6-B | JKT-TR-3X2-TN6-C | 3 x 2 | 4 | 3.75 | 4.00 |
JKT-TR-3X2.5-TN6-A | JKT-TR-3X2.5-TN6-B | JKT-TR-3X2.5-TN6-C | 3 x 2½ | 4 | 3.75 | 3.75 |
JKT-TR-4X1-TN6-A | JKT-TR-4X1-TN6-B | JKT-TR-4X1-TN6-C | 4 x 1 | 6 | 4.50 | 3.88 |
JKT-TR-4X1.5-TN6-A | JKT-TR-4X1.5-TN6-B | JKT-TR-4X1.5-TN6-C | 4 x 1½ | 6 | 4.50 | 4.00 |
JKT-TR-4X2-TN6-A | JKT-TR-4X2-TN6-B | JKT-TR-4X2-TN6-C | 4 x 2 | 6 | 4.50 | 4.50 |
JKT-TR-4X2.5-TN6-A | JKT-TR-4X2.5-TN6-B | JKT-TR-4X2.5-TN6-C | 4 x 2½ | 6 | 4.50 | 4.25 |
JKT-TR-4X3-TN6-A | JKT-TR-4X3-TN6-B | JKT-TR-4X3-TN6-C | 4 x 3 | 6 | 4.50 | 4.25 |
Concentric Jacketed ReducerJKT-RC-Size-TN6
| 316L Material Part # (Port Position A) | Product Line Size (in) | Jacket Size (in) | A (in) |
|---|---|---|---|
JKT-RC-0.75X0.5-TN6 | ¾ x ½ | 1½ | 4.50 |
JKT-RC-1X0.5-TN6 | 1 x ½ | 2 | 4.50 |
JKT-RC-1X0.75-TN6 | 1 x ¾ | 2 | 4.50 |
JKT-RC-1.5X0.5-TN6 | 1½ x ½ | 2½ | 6.00 |
JKT-RC-1.5X0.75-TN6 | 1½ x | 2½ | 5.50 |
JKT-RC-1.5X1-TN6 | 1½ x 1 | 2½ | 5.50 |
JKT-RC-2X0.5-TN6 | 2 x ½ | 3 | 10.00 |
JKT-RC-2X0.75-TN6 | 2 x | 3 | 9.00 |
JKT-RC-2X1-TN6 | 2 x 1 | 3 | 8.00 |
JKT-RC-2X1.5-TN6 | 2 x 1½ | 3 | 6.00 |
JKT-RC-2.5X1.5-TN6 | 2½ x 1½ | 4 | 8.00 |
JKT-RC-2.5X2-TN6 | 2½ x 2 | 4 | 6.50 |
JKT-RC-3X1-TN6 | 3 x 1 | 4 | 12.00 |
JKT-RC-3X1.5-TN6 | 3 x 1½ | 4 | 10.00 |
JKT-RC-3X2-TN6 | 3 x 2 | 4 | 8.50 |
JKT-RC-3X2.5-TN6 | 3 x 2½ | 4 | 6.50 |
JKT-RC-4X1-TN6 | 4 x 1 | 6 | 16.00 |
JKT-RC-4X1.5-TN6 | 4 x 1½ | 6 | 14.00 |
JKT-RC-4X2-TN6 | 4 x 2 | 6 | 12.50 |
JKT-RC-4X2.5-TN6 | 4 x 2½ | 6 | 10.50 |
JKT-RC-4X3-TN6 | 4 x 3 | 6 | 8.50 |
Eccentric Jacketed ReducerJKT-RE-Size-TN6
| 316L Material Part # (Port Position A) | Product Line Size (in) | Jacket Size (in) | A (in) |
|---|---|---|---|
JKT-RE-0.75X0.5-TN6 | ¾ x ½ | 1½ | 4.50 |
JKT-RE-1X0.5-TN6 | 1 x ½ | 2 | 5.50 |
JKT-RE-1X0.75-TN6 | 1 x ¾ | 2 | 4.50 |
JKT-RE-1.5X0.5-TN6 | 1½ x ½ | 2½ | 7.50 |
JKT-RE-1.5X0.75-TN6 | 1½ x ¾ | 2½ | 6.50 |
JKT-RE-1.5X1-TN6 | 1½ x 1 | 2½ | 5.50 |
JKT-RE-2X0.5-TN6 | 2 x ½ | 3 | 10.00 |
JKT-RE-2X0.75-TN6 | 2 x ¾ | 3 | 9.00 |
JKT-RE-2X1-TN6 | 2 x 1 | 3 | 8.00 |
JKT-RE-2X1.5-TN6 | 2 x 1½ | 3 | 6.00 |
JKT-RE-2.5X1.5-TN6 | 2½ x 1½ | 4 | 8.00 |
JKT-RE-2.5X2-TN6 | 2½ x 2 | 4 | 6.50 |
JKT-RE-3X1-TN6 | 3 x 1 | 4 | 12.00 |
JKT-RE-3X1.5-TN6 | 3 x 1½ | 4 | 10.00 |
JKT-RE-3X2-TN6 | 3 x 2 | 4 | 8.50 |
JKT-RE-3X2.5-TN6 | 3 x 2½ | 4 | 6.50 |
JKT-RE-4X1.5-TN6 | 4 x 1½ | 6 | 14.00 |
JKT-RE-4X2-TN6 | 4 x 2 | 6 | 12.50 |
JKT-RE-4X2.5-TN6 | 4 x 2½ | 6 | 10.50 |
JKT-RE-4X3-TN6 | 4 x 3 | 6 | 8.50 |
Jacketed SpoolJKT-SP-Size-TN6-Length
| 316L Material Part # | Product Line Size (in) | Jacket Size (in) |
|---|---|---|
JKT-SP-0.5-TN6-Length | ½ | 1½ |
JKT-SP-0.75-TN6-Length | ¾ | 1½ |
JKT-SP-1-TN6-Length | 1 | 2 |
JKT-SP-1.5-TN6-Length | 1½ | 2½ |
JKT-SP-2-TN6-Length | 2 | 3 |
JKT-SP-2.5-TN6-Length | 2½ | 4 |
JKT-SP-3-TN6-Length | 3 | 4 |
JKT-SP-4-TN6-Length | 4 | 6 |
Lengths available in the following sizes: 12, 24, 48, 72, 96, 120, and 240 inches
